Other attributes
| Place of Origin |
Zhejiang, China |
| Model Number |
FD-SMM EV16 |
| Brand Name |
DE DIAN FEI |
| Mechanical life |
no-load plug in/pull out>10000 times |
| Coupled insertion force |
>45N<80N |
| Operating temperature |
-30°C-+50oc |
| Case Material |
Thermoplastic, flame retardant grade UL94v-o |
| Contact bush |
Copper alloy, silver plating |
| Rated current |
16A or 32A or 40A or 50A |
| Operation voltage |
240V |
| lnsulation resistance |
>1000MΩ(DC500V) |
| Terminal temperature rise |
<50K |
| Withstand Voltage |
2000V |
Packaging and delivery
| Selling Units |
Single item |
| Single package size |
25X7X8 cm |
| Single gross weight |
0.360 kg |
Features
Meet SAE J1772-2010 standard
Eocellent protection performance,protection grade lIP44
Nice appearance, hand-held ergonomic design, easy plug
Product Paramenters
| Mechanical life |
no-load plug in/pull out>10000 times |
| Rated current |
16A or 32A or 40A or 50A |
| Coupled insertion force |
>45N<80N |
| Operation voltage |
240V |
| lnsulation resistance |
>1000MΩ (DC500V) |
| Operating temperature |
-30°C-+50°C |
| Terminal temperature rise |
<50K |
| Withstand Voltage |
2000V |
| Case Material |
Thermoplastic, flame retardant grade UL94V-0 |
| Contact Resistance |
0.5mΩ Max |
| Contact bush |
Copper alloy, silver plating |
| Model |
FD-SMM EV16 |
| Rated current |
16A |
| Cable specification |
3x2.5mm²+2x0.5mm² /3x144AWG+1X18AWG |
| Gun head | Flame retardant PA66 Nylon material |
| Handle | Flame retardant PC |
